Turnkey plant from pulping to finished board
Fiber cement board is a non-asbestos board made mainly of Portland cement, cellulose fiber and silica sand, cured in an autoclave. It combines the strength of cement with the workability of wood and is suitable for both exterior and interior use.
Typical single-line capacity: around 4–5 million m² of board per year, sized to each project.
Typical proportions; the actual recipe depends on raw materials and board type.
Length 2440 / 3050 mm · Width 1220 mm · Thickness 4–30 mm. Non-standard sizes on request.
| Item | Low density | Medium density | Medium-high density | High density |
|---|---|---|---|---|
| Density g/cm³ | 0.75 < D ≤ 0.9 | 1.2 < D ≤ 1.4 | 1.4 < D ≤ 1.5 | 1.5 < D ≤ 1.6 |
| Thermal conductivity W/(m·K) | ≤ 0.2 | ≤ 0.25 | ≤ 0.35 | ≤ 0.35 |
| Flexural strength, air-dry MPa | ≥ 8 | ≥ 11 | ≥ 18 | ≥ 21 |
| Flexural strength, saturated MPa | ≥ 6 | ≥ 8 | ≥ 14 | ≥ 17 |
| Water absorption % | ≤ 28 | |||
| Wet expansion % | ≤ 0.25 | |||
| Incombustibility | Grade A1 (GB 8624) | |||
| Impermeability | No water drops after 24 h test | |||
| Freeze test | Pass | |||
| Asbestos, formaldehyde, benzene | 100% none | |||
Tell us your board type, capacity and site conditions. Our engineers will reply with a preliminary proposal.
